FPS · CNC milling machines · Milling machines
FPS 425M-NC DualmasterCNC milling machine
- Table size
- 630×470 mm
- X/Y/Z travel
- 400–450 mm
- Spindle taper
- SK40 DIN 69871
- Power
- 13.3 kW / 15.2 kW
The FPS 425M-NC Dualmaster is a hybrid milling and drilling machine: it runs with handwheels or from a program on Heidenhain TNC 620 FS or Siemens Sinumerik ONE, and has a dual guide system, direct measuring systems and a full enclosure. Table 630×470 mm, travels 425/450/400 mm, 13.3 kW (Heidenhain) or 15.2 kW (Siemens), 0–5,000 rpm, feed and rapid traverse up to 10,000 mm/min, approx. 2,610 kg. We select workholding and tooling to suit your typical parts.
| Brand | FPS |
| Machine type | Universal CNC milling-drilling |
| Category | Milling machines · CNC milling machines |
| Working area | |
| Table size | 630 × 470 mm |
| X/Y/Z travel | 425/450/400 mm |
| Feed and rapid traverse | up to 10000 mm/min |
| Drive and output | |
| Power | 13.3 kW (Heidenhain) / 15.2 kW (Siemens) |
| Control and accuracy | |
| Control system | Heidenhain TNC 620 FS or Siemens Sinumerik ONE |
| Tooling | |
| Spindle taper | SK40 DIN 69871 |
| Dimensions and power supply | |
| Weight | approx. 2610 kg |
Additional specifications
- Dualmaster combines manual and programmed machining in one machine. It features a dual guideway system, direct measuring systems and a choice of Heidenhain TNC 620 FS or Siemens Sinumerik ONE. Spindle speed: 0–5000 rpm
- Additional Y travel of the head: 150 mm
